Vyvíječe páry elektrické pro parní ohřev minipivovarů
Elektrické vyvíječe páry jsou vhodným řešením zejména pro minipivovary menší až střední velikosti (1,5 HL – 20 HL). Hlavním důvodem pro volbu elektrického vyvíječe páry je zejména potřeba využívání horké páry pro další zařízení v pivovaru (například při sanitaci KEGů), anebo potřeba rychlé sanitace potrubních rozvodů párou.
K našim minipivovarům dodáváme elektrické vyvíječe páry včetně veškerého potřebného příslušenství a montážních prací. Dodávka elektrického vyvíječe páry obvykle obsahuje :
- Vlastní elektrický parní vyvíječ
- Nerezový zásobník napájecí/kondenzační vody s čerpadlem, řízením hladiny a teploty vody, armaturami, uzavíracími a pojistnými ventily
- Nerezové oplechování izolace
- Úpravna vody – plně automatická s filtrem mechanických nečistot
- Dávkovací odstředivé čerpadlo
- Pojistný ventil 7 bar
- Stavitelný tlakový spínač výstupní páry
- Zabudovaný elektrický rozvaděč
- Vestavěná nerezová kondenzační nádrž + hlídání teploty a hladiny
- Napojení na elektrické rozvody, vodu a kanalizaci
- Passport tlakového zařízení + výchozí revize tlakových nádob
- Elektrorevize výchozí
- Dovoz zařízení v rámci ČR (zahraničí za příplatek)
- Instalace zařízení na území ČR (zahraničí za příplatek)
Elektrické vyvíječe páry – ceník a technický popis dodávaných typů :
TSE-240 : Electric steam generator 120-240 kW | 156-312 kg/hr | 11.5 bar
Price: 24 150 €
Automatic electric hot steam-generator with capacity from 120 kW up to 240 kW (from 156 up to 312 kg of hot steam per hour) Water feed can be connected directly to the water mains or to a condensate tank. Regulation of the working steam pressure is adjustable in range from 1 to 11.5 bar. This steam-generator is available with eight heaters (8x 30 kW) . The steam-generator shell is manufactured in accordance
MXSG-12CSF : Electric steam generator GHIDINI MAXI-24 6-12kW / 8-18kg/hr | pressure from 4.5 to 7.0 bar | Complete system on the frame
Price: 10 €
Automatic electric hot steam-generator - the complete system on the frame :
- with capacity 12 kW (7.8-15.6 kg of hot steam per hour) - if returned condensate is not reused
- with capacity 12 kW (9.0-18.0 kg of hot steam per hour) - if returned condensate is reused
The compact build pre-assembled and tested steam generator with all recommended accessories. All is delivered on the stainless steel frame, with all internal connections,MXSG-12 : Electric steam generator GHIDINI MAXI-24 6-12kW / 8-18kg/hr | pressure from 4.5 to 7.0 bar
Price: 3 €
Automatic electric hot steam-generator :
- with capacity 12 kW (7.8-15.6 kg of hot steam per hour) - if returned condensate is not reused (the condesate recovery set is not included)
- with capacity 12 kW (9.0-18.0 kg of hot steam per hour) - if returned condensate is reused (the condesate recovery set is included)
MXSG-18CSF : Electric steam generator GHIDINI MAXI-24 9-18kW / 12-27kg/hr | pressure from 4.5 to 7.0 bar | Complete system on the frame
Price: 10 €
Automatic electric hot steam-generator - the complete system on the frame
- with capacity 18 kW (11.7 - 23.4 kg of hot steam per hour) - if returned condensate is not reused
- with capacity 18 kW (13.5 - 27.0 kg of hot steam per hour) - if returned condensate is reused
The compact build pre-assembled and tested steam generator with all recommended accessories. All is delivered on the stainless steel frame, withMXSG-180CSF : Electric steam generator GHIDINI MAXI-180 30-180kW / 39-270kg/hr | pressure from 4.5 to 8.5 bar | Complete system on the frame
Price: 24 €
Automatic electric hot steam-generator - the complete system on the frame
- with capacity from 30 kW up to 180 kW (from 39 up to 234 kg of hot steam per hour) – if returned condensate is not reused
- with capacity from 30 kW up to 180 kW (from 45 up to 270 kg of hot steam per hour) – if returned condensate is reused
The compact build pre-assembled and tested steamMXSG-150CSF : Electric steam generator GHIDINI MAXI-180 25-150kW / 32-225kg/hr | pressure from 4.5 to 8.5 bar | Complete system on the frame
Price: 23 €
Automatic electric hot steam-generator - the complete system on the frame
- with capacity from 25 kW up to 150 kW (from 32.5 up to 195 kg of hot steam per hour) – if returned condensate is not reused
- with capacity from 25 kW up to 150 kW (from 37.5 up to 225 kg of hot steam per hour) – if returned condensate is reused
The compact build pre-assembled and tested steamMXSG-120CSF : Electric steam generator GHIDINI MAXI-120 30-120kW / 39-180kg/hr | pressure from 4.5 to 8.5 bar | Complete system on the frame
Price: 20 €
Automatic electric hot steam-generator - the complete system on the frame
- with capacity from 30 kW up to 120 kW (from 39 up to 156 kg of hot steam per hour) – if returned condensate is not reused
- with capacity from 30 kW up to 120 kW (from 45 up to 180 kg of hot steam per hour) – if returned condensate is reused
The compact build pre-assembled and tested steamMXSG-100CSF : Electric steam generator GHIDINI MAXI-120 25-100kW / 33-150kg/hr | pressure from 4.5 to 8.5 bar | Complete system on the frame
Price: 19 €
Automatic electric hot steam-generator - the complete system on the frame
- with capacity from 25 kW up to 100 kW (from 32 up to 133 kg of hot steam per hour) – if returned condensate is not reused
- with capacity from 25 kW up to 100 kW (from 37.5 up to 150 kg of hot steam per hour) – if returned condensate is reused
The compact build pre-assembled and tested steamMXSG-80CSF : Electric steam generator GHIDINI MAXI-120 20-80kW / 26-120kg/hr | pressure from 4.5 to 8.5 bar | Complete system on the frame
Price: 18 €
Automatic electric hot steam-generator - the complete system on the frame
- with capacity from 20 kW up to 80 kW (from 26 up to 104 kg of hot steam per hour) – if returned condensate is not reused
- with capacity from 20 kW up to 80 kW (from 30 up to 120 kg of hot steam per hour) – if returned condensate is reused
The compact build pre-assembled and tested steamMXSG-60CSF : Electric steam generator GHIDINI MAXI-60 30-60kW / 39-90kg/hr | pressure from 4.5 to 8.5 bar | Complete system on the frame
Price: 13 €
Automatic electric hot steam-generator - the complete system on the frame
- with capacity from 30 kW up to 60 kW (from 39 up to 78 kg of hot steam per hour) – if returned condensate is not reused
- with capacity from 30 kW up to 60 kW (from 45 up to 90 kg of hot steam per hour) – if returned condensate is reused
The compact build pre-assembled and tested steam
